Per-Fil Micro Filler

Our Take: Professional Automation Without the Industrial Footprint

If you’re ready to stop hand-labeling but aren’t ready for a full-scale industrial line, the ELF-50 is the smartest investment you can make. We consider this the "portable powerhouse" because it offers the same rugged 304 stainless steel and anodized aluminum construction as its larger industrial cousins , but in a footprint that fits comfortably on a tabletop or bench.

Versatility is where the ELF-50 really shines. It is a true "small container specialist"—the label peel plate and upright belt can lower all the way to the conveyor height, allowing it to accurately label tiny vials and small diameter bottles that often trip up more expensive machines. With its "one-button teach" product and label sensors and a microprocessor that stores up to five job settings, you can switch between product sizes in minutes without re-entering data.

This unit provides professional, automated results at a fraction of the cost of floor-model systems. It’s easy to maintain, reliable, and most importantly, it’s built to scale with your business.

Overview:
The ELF-50 is a versatile tabletop labeling machine designed for small to medium-sized production runs. Its compact design and user-friendly features make it an excellent choice for businesses seeking efficient and precise labeling solutions.

Key Specifications:

• Label Type: Wrap-Around

• Maximum Dispensing Speed: 52.5 ft/min (16 m/min), 60 containers/min

• Maximum Conveyor Speed: 32.8 ft/min (10 m/min), 60 containers/min

• Dimensions (L x W x H): 43.3” x 34.3” x 20” (1100mm x 870mm x 508mm)

• Maximum Label Size: 4.75” x 11.8” (120mm x 300mm)

• Maximum Container Width: 6.3” (152.4mm)

• Conveyor Width: 6” (152.4mm)

• Spool Diameter: 10” (254mm)

• Inner Core: 3” (76mm)

• Power: 110/220 VAC, 50/60 Hz, 1 Phase; 0.460 kW; 2 Phase Stepper Motor

• Net Weight: Approx. 165 lbs (75 kgs)

Features:

• Portability: Can be positioned on a tabletop or bench, or moved in-line for automatic or semi-automatic applications.

• User-Friendly: One-button teach product and label sensors; manual position setting for accurate label placement.

• Upgradable: Can be upgraded to activate hot-foil printer controls for label customization.

• Productivity Features: Production preset function, label count feature, and container/production run counter.

• Memory Retention: Battery-free microprocessor control system that maintains default settings and memory even after the machine sits idle for a long period.

• Durability: Made of 304 stainless steel and anodized aluminum, ensuring longevity and compliance with Good Manufacturing Practices (GMP) standards.

Ideal Applications:
Perfect for small-scale production in industries such as food, beverage, cosmetics, and pharmaceuticals.
